Automatic door OPERATOR OF SINGLE / BI-PARTING DOOR (AD-3)
AD-300 SERIES SINGLE / BI-PARTING DOOR
Feature
- User-Friendly, Unsurpassed Quality
- Auto-return Safe Function
- High Range AC Voltage Input
- Super Efficient Electricity-Saving Function
- Power saving, Quietest, Firm and Durable, Starting Power swift
- Safety Approval: URS ISO 9001, CE
- USER FRIENDLY design.
- High range AC voltage input function-AC80V to AC250V.
- “ Catch Return" function-the door can return when it hits against obstacle during opening/closing movement.
- Direct connection to the optional devices enabled, ex. ELECTRIC LOCK, SAFETY BEAM, UPS (BATTERY) etc...
Specification
| TYPE |
AD-3 |
| MODEL |
SINGLE-WINGED |
BI-PARTING |
| DOOR WEIGH |
150kgX1 door |
130kgX2doors |
| DOOR WIDTH |
DW=500mm~2500mm |
DW=500mm~2500mm |
| INSTALL WAY |
Surface install |
Surface install |
| MOTOR |
DC 24V 75W Worm Gear Motor |
| CONTROL |
Micro-Controller |
| POWER CONSUPTION |
75 W |
| VOLTAGE |
AC 80V~250V |
| ENVIROMENTAL TEMPERATURE |
-20℃~+50℃ |
| VOLUME |
60 decibel (max.) |
| STARTING SPEED |
600mm/second |
550mm/second |
| STARTING TIME |
0~20sec. (regulable) |
| TRANSMISSION IMPORTANT CONDITION |
Rack Belt 150 S8M |
| OPENING DOOR RANGE |
Full/Half-Open |
| PFC POWER EFFICIENCY |
0.95(AC100V Full Load) |
| TRACTION FORCE |
3.5kg |
|
 |
|
