SLIDING DOOR » CUTECH SERIES (TAIWAN) - TELESCOPIC

TH-W2/TH-W3 and AD-W2/AD-W3

 Feature
  • Maximum use in a limited space. It's suitable for places where a wider opening required
  • Unique Aluminum Track design
  • Elegant Appearance for any buildings and architesture
  • Highly using spaces for more room
  • Excellent Quality & High-performance


 Specification

TELESCOPIC DOOR MOLD: AD-W2 MOLD: TH-W2
2-WINGED 4-WINGLED 2-WINGLED 4-WINGLED
DOOR WEIGH 130kgX2 door 90kgX4 doors 130kgX2doors 90kgX4 doors
DOOR WIDTH DW=500mm~3000mm DW=500mm~3000mm
INSTALL WAY Surface install Surface install
MOTOR DC24V 75W WORM GEAR MOTOR DC24V 75W BRUSHKESS DC MOTOR
CONTROL USER-FRIENDLY
MICRO-CONTROLLER		 STANDARD
MICRO-CONTROLLER
POWER CONSUPTION 75 W
VOLTAGE AC 80V~250V
ENVIROMENTAL
TEMPERATURE		 -20℃~+50℃
VOLUME 60 decibel (max.)
STARTING SPEED 650mm/second 600mm/second 650mm/second 600mm/second
STARTING TIME 0~20sec. (regulable)
TRANSMISSION
IMPORTANT
CONDITION		 Rack Belt 150 S8M
OPENING DOOR RANGE Full/Half-Open (regulable)
PFC POWER EFFICIENCY 0.95(in AC100V Full Load)
TRACTION FORCE 3.5kg 3kg
